XE-20 Series
Highly versatile, reliable compact, and rugged edge computing LTE Modem
Niseva Technologies aims to significantly simplify and accelerate complex IOT deployments by bridging heterogeneous systems with various different hardware interfaces and software protocols into one single standard-based platform. XE-20 Modem series is a highly ruggedized and at the same time versatile, Intelligent, and secure 4G Cellular edge computing device.
With most essential hardware interfaces available natively on the device, and support of industrial protocols like Modbus, DLMS, the device is particularly suitable for Automation / Metering applications. From seamless Sensor integration to PLC/RTU/Meter integration coupled with Niseva XNET platform ensures easy device setup, configuration, Device Management as well as Data Management.
Device Specifications
Hardware Interfaces for XE-20
1 X Full RS232 via RJ45
1 X USB 2.0 up to 480Mbps
1 X SIM 1.8V/3.0V
1 X e-Sim
2 X Digital Inputs (up to VCC)
Optional interfaces for XE-20
GNSS – GPS. Glonass, Galileo
Cellular
LTE FDD: B1/B3/B5/B7/B8/B20
LTE TDD: B38/B40/B41
WCDMA: B1/B5/B8
GSM: B3/B8
Data Rates
LTE CAT 4:
LTE FDD: 150Mbps (DL)/ 50Mbps (UL)
LTE TDD: 130Mbps (DL)/ 30Mbps (UL)
UMTS:
DC-HSDPA: 42Mbps (DL)
HSUPA: 5.76Mbps (UL)
WCDMA: 384Kbps (DL)/384Kbps (UL)
GSM:
EDGE: 296Kbps (DL)/236.8Kbps (UL)
GPRS: 107Kbps (DL)/85.6Kbps (UL)
Dimensions:
Ultra compact form factor –
55mm x 45mm x 20mm
Power Supply
8-32 VDC
Power supply from RJ 45 as well as
separate power input
Last Gasp – Power loss detection
via Super Capacitors
Power Consumption at 12V DC
Sleep Mode: 3mA
Idle Mode: 22mA
LTE CAT4: 330mA
Operating Temperature
-30 to 85 degree Celsius
External Hardware Watchdog
Cellular Network Watchdog
Operation Protocols
PPP, QMI, CMUX, SSL
Plug and Play Software
AT Command support
Auto TCP – Server and Client Mode
LED Indicators
Power LED
Device Status
Net Mode for device Network Registration
Net status – Device Data connection
